II MZ-64P

     The MZ-64P is a zone control pre-amplifier. Containing four individual distribution zones and five fully featured input channels, audio can be directed accordingly. A dedicated fire/emergency input can override the system. The steel 1U housing is extremely robust and front controls are easy to operate. Front 'scribble' strips allow each zone and input identification. The perfect installation pre-amplifier for retail, leisure, café, bars and halls.


     MZ-64P는 존 컨트롤 프리앰프입니다. 4개의 개별 분배 존과 5개의 완전한 기능을 갖춘 입력 채널을 탑재하여, 오디오를 용도에 맞게 라우팅할 수 있습니다. 전용 화재/비상 입력은 시스템을 오버라이드할 수 있습니다. 스틸 소재의 1U 하우징은 매우 견고하며, 전면 컨트롤은 조작이 쉽습니다.

전면의 ‘스크리블’ 스트립을 통해 각 존과 입력을 쉽게 식별할 수 있습니다. 리테일 매장, 레저 시설, 카페, 바, 홀 등에 적합한 완벽한 설치용 프리앰프입니다.


  • 4 zone preamplifier
  • 5 comprehensive audio input channels
  • Balanced Euroblock line outputs per zone
  • Independent bass and treble EQ adjustment on each zone
  • Compact space saving fan-less 1U design (rack mountable)
  • Universal ~100-240V worldwide operation
  • Remote volume control capability using HH MZ-C2 module and standard ethernet cable



II FEATURES

System Type
Zone preamplifier with input routing
Inputs
CH1/2 balanced XLR/6.3mm jack combi socket, CH3/4 L&R balanced 3.5mm Euroblock, CH5 3.5mm stereo aux and stereo RCA
Outputs
3.5mm Euroblock connectors for each zone
Indicators
Power/Standby, Input signal present and peak LEDs, Output signal present and clip LEDs
Controls
Adjustable gain control for each input; source select and volume control for all zones
Frequency Response

20-20kHz ±0.1dBu
THD+N
<0.008% @0dBu in, maximum volume; <0.005% @+6dBu in, maximum volume
S/N
>110dB
Noise Floor
< -90dBu
Crosstalk
< -105dB between channels, maximum volume
Emergency Override
Balanced 3.5mm Euroblock connector, overriding the normal inputs
Lineout
3.5mm Euroblock line level output that follows zone 1, useful for system expansion
Other Controls
CH1/2 Mic/line level, phantom power; individual zone limiters with 0dBu/+4dBu modes; front panel lock
DSP

ORIGIN advanced multicore platform
EQ
Each zone has bass and treble shelving control with a low pass filter mode; switchable high pass filter on CH1/2
Power Consumption
<8W Typical, <30W Maximum
Unit Dimensions (Hwd)
44 x 483 x 198 mm (1.7" x 19" x 7.8")
Unit Weight
2.3kg, 5.1lbs
Carton Dimensions (Hwd)
150 x 630 x 290 mm (5.9" x 24.8" x 11.4")
Packed Weight

3.8kg, 8.4lbs
Accessories
Rack mounting kit, Euroblock connectors (8x 3.5mm 3 way, 2x 3.5mm 5 way, IEC mains lead, HH user manual download card


II DOWNLOADS

MZ SERIES INSTALL ZONE AMPLIFIERS, PRE-AMP & CONTROLLERS


The MZ Series is perfect for those needing to control audio for several zones. The range includes 4 zone amplifiers, one pre-amp, and sleek wall controllers in either black or white and available as EU or US standard plates.
