II TNA-2800SA

    TESSEN LINE ARRAY SERIES

II TNA-2800SA

     TNA-1800S 패시브 라인 어레이 서브우퍼는 뛰어난 고출력을 제공하는 고출력 18인치 저역 우퍼를 탑재하고 있습니다. 통합 리깅 하드웨어를 갖추고 있어 TNA-1800S를 빠르고 간편하게 설치할 수 있습니다. TNA-1800S는 최대 127dB SPL을 제공하며, 32Hz까지 내려가는 저역 주파수 응답을 지원합니다. TNA-2051 및 TNA-1200S와 함께 사용할 경우, TNA-1800S는 공연장 설치 또는 포인트 소스 솔루션으로 이상적인 구성을 제공합니다. 공연장, 학교, 스포츠 시설, 체육관, 호텔 등 다양한 환경에 적합합니다.

II FEATURES





Accessories

4 x Heavy Duty 100mm PU Castors included in the box)

System Type

Dual 18" Active Subwoofer, Direct Radiating, Bass Reflex

Frequency Response (-10)

32Hz - 100Hz

Frequency Response (-3)

37Hz - 100Hz

LF Driver

2 x 18-inch High sensitivity HH designed driver. 4-inch Voice Coil

Max SPL

144 dB

Crossover Frequency

Active - 70Hz to full range

Power

8000W Peak, 4000W Continuous, 2000W RMS

Input Sensitivity

0dBu to +10dBu Adjustable

Input Connector

Balanced Female XLR

Output Connector

Balanced Male XLR (Switchable Full Range/Xover)

Controls

Input sensitivity, Crossover frequency, Phase Switch, Variable Delay (0>9.9mS)

Cabinet

Acoustically optimised 18mm plywood cabinet with extensive internal bracing
Finish
Painted Black (White finish optional, subject to MOQ)

Mounting Points

8x M10 Penn Elcom tie down/flying points. 16x M8 inserts for included transport wheels
Grille
1.5mm Thickness Steel, Hexagonal mesh, acoustic foam lined

Unit Dimensions (Hwd)

562 x 1080 x 685mm, (22.1" x 42.5" x 27")

Unit Weight

77.7Kg, 171 lbs

Carton Dimensions (Hwd)

700 x 1280 x 815mm, (27.6" x 50.4" x 32.1") , (0.73 M3)

Packed Weight

91Kg, 201 lbs

II DOWNLOADS

PASSIVE AND ACTIVE LINE ARRAY


The HH TNA series is the perfect long throw solution for powerful and immersive fixed installation sound. The TNA offers flexible configurations to allow for fully customisable experiences for the venue or application at hand. Suitable for large venues


Available as optional extras: the TNA-BRK1-G3 allows suspended install of the TNA-2051-G3, TNA-1200S-G3 or TNA-2120SA-G3 models.
